Description
Specifications:
- Keyboard : 61 standard size keys
- Touch Response: Sensitivity 3 types, Off
- Maximum Polyphony : 64 notes (32 for certain tones)
Tones
- Preset Tones: 800
- User Tones: 100
- Other: Layer, split (configurable split point, lower point, chord point settings)
System Effects
- Reverb: 24 types, Off
- Chorus: 12 types, Tones
- Delay: 15 types, Tones
- DSP: 100 types (Can be applied to user tones using DSP editing.), DSP tones
Master Effects
- Equalizer (10 presets)
- External Input Effects :
- Center cancel (vocal cut) for input from the Audio In jack
Metronome
- Beat: 0 (accented tone off), 1 to 16
- Tempo: Tempo value: 20 to 255
- Demo Songs : 3
Song Bank
- Built-in Songs: 30
- User-recorded Songs: 10
- USB Memory Songs: Playback of standard MIDI files (SMF format 0/1), CASIO MIDI files (CMF format) on a USB flash drive is supported.
- USB Audio Playback : Playback of audio files on a USB flash drive is supported.
- Supported File Formats: WAV format, 44.1 kHz 16 bit
- Other Functions: Center Cancel (Vocal Cut)
- Auto Accompaniment : Built-in Rhythms: 250
- User Rhythms: 50
- One Touch Presets 235
- Music Presets : 310 (With chord progressions)
Phrase Pads
- Number of Pads: 4
- User Phrases: 100 (4 phrases x 25 pads)
- Editing Mode: Copy, delete, phrase editing
Mixer function
- Affected Parts: Sound source parts, microphone input part
- Parameters: Part on/off, volume, pan, reverb send, chorus send, delay send
- Registration : Maximum 128 setups (8 setups x 16 banks), registration sequence
- Tone Editing : Preset tone editing, DSP editing
- Memory for storage of edited tones (up to 100)
- Rhythm Editing : New rhythm creation, rhythm editing
- Memory for storage of created/edited rhythms (up to 50)
- MIDI Recorder : Real-time recording, playback
- Keyboard Performance Recording: 10 songs, 17 tracks (1 system track, 16 solo tracks)
- Memory Capacity: Approximately 40,000 notes (per song)
- Editing Mode: Song editing, track editing, event editing, step input
- Other Functions: Overdubbing, punch-in recording
- Pedals : Sustain, sostenuto, soft, rhythm/song, expression
- Controllers : Pitch bend wheel, SUSTAIN button, PORTAMENTO button
Other Functions
- Transpose: ±1 octaves (-12 to 0 to +12 semitones)
- Octave Shift: Upper 1/Upper 2/Lower 1/Lower 2, ±3 octaves
- Tuning: A4 = 415.5 to 465.9 Hz (Initial Default: 440.0 Hz)
- Part coarse tune: For each keyboard part, ±2 octaves (-24 to 0 to +24 semitones)
- Part fine tune: For each keyboard part, ±99 cents
- Scales: 17 preset scales, scale fine tuning
- Auto Harmonize: 12 types
- Arpeggiator: 150 types
- MIDI : 16ch multi-timbre received, GM Level 1 standard
- Inputs/Outputs : USB Flash Drive Port: Type A
- USB Port: Type B
- Pedal 1 Jack: Standard jack
- Pedal 2, Expression Jack: Standard jack
- Headphones Jack: Stereo standard jack
- Audio Input Jack: Stereo mini jack/Input impedance 9 k?, Input sensitivity 200 mV
- Power Jack : DC 12V
- Power Supply : 2-way
- AC Adaptor: AD-A12150LW
- Batteries: 6 D-size alkaline batteries
- Battery Life: Approximately 10 hours continuous
- Auto Power Off: Approximately 30 minutes after last operation; Can be disabled.
- Speakers : 10cm x 2 (Output: 6W + 6W)
- Power Consumption : 8 W
- Dimensions : W 94.8 x D 38.4 x H 11.6 cm
- Weight : Approximately 6.9 kg (without batteries)
- Included Accessories : Music stand, AC adaptor
